GENERAL APPLICATIONS
CVB Dumper Butterfly Valves DMR series have excellent performance, high reliability, easy maintenance to allow accurate directional flow control in any gas circulation system.
Core Features
- Monobloc or fabricated body
- Low pressure drop
- Additional thrust bearing
- Wide range of materials
Benefits of DMR Series
Body:
- Available for wafer or flanged style
- Ensuring maximum performance and reliability
- Guaranteeing lightness
- Available with extended neck to enable piping insulation
Disc:
- Design to minimize pressure drop
- Light design to easy controllability
- Light construction with reinforcing ribs to ensure low operating torque
Shaft:
- Double shaft or (upon request) single shaft design to guarantee higher torsional resistance
- Extended shaft to allocate additional bearing to reduce friction and avoid bending
Actuation:
- Top flange allows easy coupling to manual, pneumatic and electric actuators
- ISO 5211 standard
Product Specifications
Production Range |
Nominal diameter 3” – 120” (80 - 3000 mm) larger size upon request |
Pressure Limit |
From vacuum up to +6 bar (88 psi) |
| Please refer to relevant technical brochure related to tightness class | Applicable Standards |
Design: ANSI B16.34/ ASME VIII/ API 609 |
| Face to face: API 609 A / ISO 5211 / DIN 3337 | |
| Flange: B16.5 / B16.47 / ASME VIII / DIN / ISO/ UNI | |
| Testing: API 598 | |
| Fugitive emission: ISO 150484-1 | |
| NORSOK |
Temperature Limits |
From -20°C (-4°F) up to +818°C (+1600°F) |
| Please refer to relevant technical brochure related to seat material | |
Body Style |
Wafer |
| Double Flanged | |
| For FtF dimensions, please refer to relevant technical brochure | |
Materials |
Carbon Steel |
| Stainless Steel | |
| Other materials available upon request | |
Ratings |
NP 2,5 - 6 |
| Higher pressure upon request |
